Teltonika ATC774 4G LTE — Rechargeable battery
€82.00
Tax excluded
TELTONIKA ATC774 3200MAH RECHARGEABLE
The rechargeable Teltonika ATC774 4G LTE is a professional standalone GPS tracker for vehicles, trailers, containers and mobile equipment. Its 3,200 mAh rechargeable Li-ion battery suits assets regularly accessible for maintenance. Without permanent wiring, it combines LTE Cat 1 connectivity, multi-constellation GNSS and an IP68 enclosure. Periodic reporting, movement-based tracking and the scheduler tailor location updates to operational needs. Recharging requires an external charger compatible with the batteries used.
Hurry up! Only
5
item(s) left in Stock!
Teltonika ATC774: rechargeable standalone GPS tracker
3,200 mAh rechargeable battery for regularly serviced assets
This version uses a 3,200 mAh, 3.7 V rechargeable Li-ion battery. It suits equipment that returns to a depot regularly or remains accessible during maintenance. Runtime between charges depends on configuration and reception conditions. The primary-battery version’s “up to 10 years” claim does not apply to a single charge of this version. Manufacturer guidance requires a compatible external charger for rechargeable batteries.
Professional location tracking without permanent power
Monitor trailers, containers and equipment without a continuous power supply. The Teltonika ATC774 also provides standalone tracking for vehicles and equipment temporarily assigned to a work site, project or rental contract. Installation without wiring supports deployments on moving assets or equipment stored at remote sites. Position the device to maintain adequate satellite and cellular reception.
4G LTE Cat 1 connectivity and GNSS positioning
The GNSS receiver supports GPS, GLONASS, Galileo and BeiDou. LTE Cat 1 transmits location records to a compatible server over TCP or UDP. Codec 8 Extended supports integration with a telematics platform that explicitly supports the model. The modem variant and network bands must match the countries of use. This model uses LTE Cat 1, distinct from the ATM700’s LTE-M technology.
Movement-based tracking, periodic reporting and scheduling
The accelerometer, periodic location updates and scheduler let operators adapt reporting to how assets are used. A stationary trailer may require a different reporting pattern from equipment moving daily. Reporting frequency and sleep settings directly influence battery life: the maximum operating lifetime does not represent continuous high-frequency tracking.
IP68 enclosure and telematics administration
The IP68 enclosure protects against dust and water for outdoor deployments within the manufacturer’s specified conditions. Internal memory stores records, an RGB LED indicates status and the USB-C interface supports configuration. FOTA WEB and Telematics Configuration Tool (TCT) support configuration and updates according to connection conditions.
Deployment requirements: a Nano-SIM with suitable data service, operator connection settings and an ATC774-compatible platform. Available user functions depend on the selected configuration and platform.
Technical specifications
| Battery version | Rechargeable Li-ion |
|---|---|
| Capacity and voltage | 3,200 mAh, 3.7 V |
| Battery life | Depends on tracking settings and conditions; no 10-year single-charge claim |
| Recharging | Compatible external charger; USB-C is not advertised as built-in battery charging |
| Charging temperature | 0 °C to +45 °C |
| Technology | 4G LTE Cat 1 |
| Positioning | GPS, GLONASS, Galileo, BeiDou |
| GNSS receiver | 135 tracking/acquisition channels |
| Position accuracy | < 1.8 m CEP |
| GNSS sensitivity | −165 dBm |
| Hot / warm start | < 1 s / < 25 s |
| 4G bands — EU version (QMA) | LTE FDD B1/B3/B5/B7/B8/B20/B28 |
| Maximum data rates | 10 Mbps download; 5 Mbps upload |
| Communication | SMS (TEXT, PDU), TCP, UDP |
| Data codec | Codec 8 Extended |
| Enclosure | IP68 |
| Dimensions | 156 × 70 × 25.2 mm |
| Weight — EU version | 251 g |
| Operating temperature | −20 °C to +60 °C |
| Humidity | 5–95%, non-condensing |
| Antennas | Internal high-gain GNSS and cellular antennas |
| SIM card | Nano-SIM |
| Configuration interface | USB 2.0 Type-C |
| Memory | 16 MB internal flash memory |
| Indicator | 1 RGB status LED |
| Sensor | Accelerometer |
| Tracking modes | Periodic tracking, movement-based tracking, scheduler |
| Power saving | Custom sleep mode |
| Configuration and firmware updates | FOTA WEB, Telematics Configuration Tool (TCT) |
| Time synchronisation | GNSS, NITZ, NTP |
| Bluetooth and EYE accessories | Bluetooth 5.3 LE and EYE support marked as under development in the manufacturer datasheet; not advertised as available |
