TELTONIKA TFT100 - RS232
€52.99
Tax included
The TELTONIKA TFT100 RS232 price, at the best price, is a robust and professional 2G GPS tracker designed for electric mobility, heavy machinery, and industrial equipment. It combines high-gain internal GNSS/GSM antennas, Bluetooth® LE support, an internal 1800 mAh Li-ion battery, and a wide 10-97 V power supply, making it suitable for forklifts, e-scooters, e-mopeds, construction equipment, trailers, or any high-voltage machine. Its IP67 waterproof housing ensures protection against water and dust for outdoor use or in harsh conditions. The TFT100 offers numerous interfaces (CAN, RS232, RS485, UART, 1-Wire, analog and digital inputs/outputs).
Sorry, no items left.
The TELTONIKA TFT100 RS 232 price, at the best price, is a robust and professional 2G GPS tracker designed for electric mobility, heavy machinery, and industrial equipment. It combines high-gain internal GNSS/GSM antennas, Bluetooth® LE support, an internal 1800 mAh Li-ion battery, and a wide 10-97 V power supply, making it suitable for forklifts, e-scooters, e-mopeds, construction equipment, trailers, or any high-voltage machine. Its IP67 waterproof housing ensures protection against water and dust for outdoor use or in harsh conditions. The TFT100 offers numerous interfaces (CAN, RS232, RS485, UART, 1-Wire, analog and digital inputs/outputs).
Teltonika TFT100 – Technical Specifications
| MODULE | Teltonika TFT100 |
|---|---|
| Technology | GSM / GPRS / GNSS / Bluetooth LE |
| GNSS | |
| GNSS systems | GPS, GLONASS, GALILEO, BEIDOU |
| Receiver | 33 tracking channels |
| Tracking sensitivity | -165 dBm |
| Position accuracy | < 2.5 m CEP |
| Hot start | < 1 s |
| Warm start | < 25 s |
| Cold start | < 35 s |
| CELLULAR | |
| Network | 2G (GSM / GPRS) |
| 2G bands | Quad-band 850 / 900 / 1800 / 1900 MHz |
| Data transfer | GPRS Multi-Slot Class 12 (up to 85.6 kbps DL/UL) |
| Data support | SMS (text/data), TCP/UDP, network protocols |
| Power | |
| Input voltage range | 10 – 97 V DC (wide range, for high-voltage machines) :contentReference[oaicite:1]{index=1} |
| Internal backup battery | 1800 mAh Li-Ion, 3.7 V (≈ 6.66 Wh) :contentReference[oaicite:2]{index=2} |
| Interfaces | |
| CAN / RS232 / RS485 / UART | 1 (type dépend de la version commandée) :contentReference[oaicite:3]{index=3} |
| Digital inputs | 4 (configurables) :contentReference[oaicite:4]{index=4} |
| Analog inputs | 2 :contentReference[oaicite:5]{index=5} |
| Digital outputs | 2 (configurables) :contentReference[oaicite:6]{index=6} |
| 1-Wire Data / Power | 1 / 1 (pour iButton / RFID / capteurs 1-Wire) :contentReference[oaicite:7]{index=7} |
| Bluetooth | Bluetooth 4.0 + LE (capteurs BLE, beacons, capteurs externes) :contentReference[oaicite:8]{index=8} |
| GNSS & GSM antennas | Antennes internes high-gain :contentReference[oaicite:9]{index=9} |
| USB | Micro-USB 2.0 (configuration / firmware update) :contentReference[oaicite:10]{index=10} |
| SIM slot | Micro-SIM :contentReference[oaicite:11]{index=11} |
| Memory | 128 MB internal flash (logging / offline storage) :contentReference[oaicite:12]{index=12} |
| Physical | |
| Dimensions (L × W × H) | Approx. 72.5 × 73 × 27.3 mm :contentReference[oaicite:13]{index=13} |
| Weight | ≈ 169 g :contentReference[oaicite:14]{index=14} |
| Ingress protection | IP67 – résistant à l’eau et à la poussière, usage extérieur / industriel possible :contentReference[oaicite:15]{index=15} |
| Operating environment | Temperature / humidity, compatible usage machines & véhicules électriques, chariots, remorques, etc. :contentReference[oaicite:16]{index=16} |
| Features | |
| Sensors | Built-in accelerometer (movement / motion / tamper detection) :contentReference[oaicite:17]{index=17} |
| Scenarios & functions | Tracking GNSS + cellular, logging interne, monitoring machines & mobility (e-scooter, e-forklift, matériel électrique), capteurs externes via Bluetooth, lecture données via CAN/RS232/RS485/UART, 1-Wire (iButton / RFID), alertes, sorties digitales, compatibilité forte-voltage, etc. :contentReference[oaicite:18]{index=18} |
| Sleep modes & power saving | GPS Sleep, Deep Sleep, Ultra Deep Sleep, Online Deep Sleep (optimisation conso) :contentReference[oaicite:19]{index=19} |
| Configuration & firmware update | Via Micro-USB, Bluetooth, ou configuration via GPRS / SMS (selon version) :contentReference[oaicite:20]{index=20} |
| Use cases / Availability | |
| Typical uses | Véhicules électriques, chariots élévateurs, trottinettes / scooters / motos électriques, machines industrielles, matériel lourd, mobilité électrique, suivi flotte heavy-duty, gestion e-mobility, tracking outdoor & industriel. :contentReference[oaicite:21]{index=21} |
